FRP Membrance Housing


SPECIFICATION

SSS4040E-F

SSS4040S-F

SSS8040E-F

SSS8040S-F

SSS8040S-F

Vessel Diameter

4 inch

4 inch

8 inch

8 inch

8 inch

Membrane Length

40 inch

40 inch

40 inch

40 inch

40 inch

Port Design

End

Side

End

Side

Side

Design Pressure

300 psi

300 psi

300 psi

300 psi

1200 psi

Test Pressure

450 psi

450 psi

450 psi

450 psi

1800 psi

Operating pH Range

3-11

3-11

3-11

3-11

3-11

Operating Temperature

-7°C - 49°C

-7°C - 49°C

-7°C - 49°C

-7°C - 49°C

-7°C - 49°C

Cleaning pH Range

2-12

2-12

2-12

2-12

2-12

No. of Membranes

1 - 4 pcs.

1 - 4 pcs.

1 - 7 pcs.

1 - 7 pcs.

1 - 7 pcs.

M°C

FRP

FRP

FRP

FRP

FRP

Membrane components…..

  • Dow, GE, K°Ch, Hydranautics, Saehan, Toray, TRISEP membrane components of other standards


Quality Assurance…

  • 100% pressure vessels were tested with 1.5 times design pressure
  • 100% pressure vessels have their own numbers, we can trace them
